Brand
SAPPHIRE
Series
TOXIC
Model
11308-08-20G
Interface
Interface rnPCI Express 4.0
Chipset
Chipset Manufacturer
AMD
GPU Series
AMD Radeon RX 6000 Series
GPU rnRadeon RX 6900 XT
Boost Clock rn2525 MHz
Stream Processors rn5120 Stream Processors
Memory
Effective Memory Clock rn16 Gbps
Memory Size
16GB
Memory Interface rn256-Bit
Memory Type
GDDR6
3D API
DirectX rnDirectX 12 Ultimate
Ports
Multi-Monitor Support
4
HDMI rn1 x HDMI 2.1
DisplayPort rn3 x DisplayPort 1.4
Details
Max Resolution
7680 x 4320
Virtual Reality Ready
Yes
Cooler
Hybrid Cooler
Operating Systems Supported
Linux, Windows 7*, Windows 10, and Windows 8.1. 64-bit operating system required
* Does not support all features including but not limited to Hardware Raytracing.
Thermal Design Power rn<430W
System Requirements
PCI Express compatible motherboard with one x16 PCIe slot.
System Chassis with space able to be installed with 360mm radiator.
Minimum 850W or greater power supply NOTE: Minimum recommended system power supply wattage is based on the specific graphics card and the typical power requirements of other system components. Your system may require more or less power. OEM and other pre-assembled PCs may have different power requirements.
Minimum 8GB of system memory. Recommended 16GB.
Installation software requires a keyboard, a mouse, and a display.
A display with HDMI, or DisplayPort is required.
Supported operating systems include Linux, Windows 7*, Windows 10, and Windows 8.1. 64-bit operating system required. (* Does not support all features including but not limited to Hardware Raytracing.)
DirectX 12 and Vulkan support
For information on AMD Radeon VR Ready Premium visit amd.com/VRready.
Recommended PSU Wattage
850W
Power Connector
2 x 8-Pin + 1 x 6-Pin
Features
Features
Sapphire
