Highlights
We took a deliberate, inward look at the fundamental shapes that comprise an in-ear. The inner facet is sculpted, both for comfort and aesthetic completeness.
ZEN Reborn With Trickle-down Technology
The vent for DUNU'S proprietary Air Control Impedance System (ACIS) the spiral bass reflex system is the centerpiece for ZEN's circular theme. The original ZEN prototype was based on PVD beryllium driver technology developed in 2018.
A High Displacement, Composite Driver Design
ZEN's nanoporous amorphous carbon diaphragm coating (nanoDLC) contains the highest ratio of sp3-to-sp2 hybridized carbon currently achievable, and is deposited via a high temperature, filtered, pulsed cathode arc deposition technique compatible only with metal substrates (polymer substrates will melt and deform). The process allows for fewer gaps and surface imperfections, bringing the layer ever closer to pure diamond.
DUNU ECLIPSE
ECLIPSE is a next-generation paradigm for dynamic drivers. External ring-type magnet assembly rated to over 1.8 Tesla the field strength at the coils This billet-machined, Custom Neodymium magnet assembly is the standard-bearer for driver control.
Technical Specifications
BRAND: DUNUrn MODEL: ZEN (禪)rn NET WEIGHT: 21 grn FREQUENCY RESPONSE: 5 Hz – 40 kHzrn SENSITIVITY: 112 ± 1 dB at 1 kHzrn IMPEDANCE: 16 Ω at 1 kHzrn TOTAL HARMONIC DISTORTION: < 0.2% at 1 kHz
rnDRIVE MODULE
DIAPHRAGM: Magnesium-Aluminum alloy dome with nanoporous amorphous carbon coating (nanoDLC)and fully independent suspension surroundrn MAGNET ASSEMBLY: > 1.8 T External Ring-Type Neodymium Magnet
rnHOUSING
MATERIAL: 316 Stainless Steelrn INTEGRATION(S): Patented Air Control Impedance System (ACIS)
rnIN THE BOX
DUNU ZEN IEMrn LENGTH: 1.2 ± 0.1 mrn MATERIAL: 8 Core, High-Purity Monocrystalline Silver-Plated Copper Litz Wire, Concentrically Arrangedrn CABLE CONNECTOR: Patented Catch-Hold® MMCX Connectorrn PLUG CONNECTOR: Patented DUNU Quick
